WinnerProPlus
Winner Pro+ 1–10kVA Online UPS
High-efficiency online UPS with LCD and SNMP
Nominal Voltage
110/115/120/127 VAC or 200/208/220/230/2
Transfer Time
AC Mode to Battery Mode
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Winner Pro+ 1K
CAPACITY
1000 VA / 900 W
PHASE
Single phase with ground
Voltage Range
60-145 VAC or 120-300 VAC (Based on load at 50%); 90-145 VAC or 180-280 VAC (Based on load at 100%)
Frequency Range
40Hz ~70 Hz
Power Factor
≧ 0.99 @ Nominal Voltage (100% load)
Voltage Regulation
± 1%
Output Voltage
110/115/120/127 VAC or 200/208/220/230/240 VAC
Frequency Range (Batt. Mode)
50 Hz or 60 Hz ± 0.5%
Waveform (Batt. Mode)
Pure Sine Wave
Current Crest Ratio
3:1
Harmonic Distortion
≦ 3% THD (Linear Load); ≦ 6% THD (Non-linear Load)
Frequency Range (Synchronized Range)
47~53 Hz or 57~63 Hz
Battery Mode
83%
AC Mode
88%
Long-run Model
Battery Type
Standard Model
Battery Type
LCD
Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
Low Battery
Sounding every second
Overload
Sounding twice every second
Fault
Continuously sounding
Operating Humidity
20~90% RH @ 0- 40°C (non-condensing)
Noise Level
Less than 50dB @ 1 Meter
Optional SNMP
Power management from SNMP manager and web browser
Smart RS-232 / USB
Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8/10, Linux, and MAC
Winner Pro+ 1K
1000 VA / 900 W
Winner Pro+ 2K
2000 VA / 1800 W
Winner Pro+ 3K
3000 VA / 2700 W
Winner Pro+ 6K
6000 VA / 5400 W
Winner Pro+ 10K
10000 VA / 9000 W
