Winner Pro 1–10kVA Online UPS
True double-conversion online UPS for SMB servers
Nominal Voltage
110/115/120/127VAC or 208/220/230/240VAC
Transfer Time
AC Mode to Battery Mode
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Winner Pro1K (L)
CAPACITY
1000 VA / 800 W
PHASE
Single phase with ground
Input Voltage Range
55-150 VAC or 110-300 VAC (Based on load at 50%); 85-140VAC or 160-280VAC (Based on load at 100%)
Frequency Range
40Hz ~70 Hz
Power Factor
≧ 0.99 @ Nominal Voltage (100% load)
Voltage Regulation
± 1%
Output Voltage
110/115/120/127VAC or 208/220/230/240VAC
Frequency Range (Batt. Mode)
50 Hz ± 0.25 Hz or 60 Hz ± 0.3 Hz
Current Crest Ratio
3:1
Harmonic Distortion
≦ 3% THD (Linear Load); ≦ 6% THD (Non-linear Load)
Frequency Range (Synchronized Range)
47~53 Hz or 57~63 Hz
Battery Mode
83%
AC Mode
88%
Long-run Model
Battery Type
Standard Model
Battery Type
LCD
Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
Low Battery
Sounding every second
Overload
Sounding twice every second
Fault
Continuously sounding
Operating Humidity
20~90% RH @ 0- 40°C (non-condensing)
Noise Level
Less than 50dB @ 1 Meter
Optional SNMP
Power management from SNMP manager and web browser
Smart RS-232 / USB
Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8/10, Linux, and MAC
Winner Pro1K (L)
1000 VA / 800 W
Winner Pro 2K (L)
2000 VA / 1600 W
Winner Pro 3K (L)
3000 VA / 2400 W
Winner Pro 6K (L)
6000 VA / 4800 W
Winner Pro 10K (L)
10000 VA / 8000 W
