Victor 1U 6kVA Lithium UPS
1U rack lithium UPS for edge and network rooms
Capacity
3Ah
Nominal Voltage
208*/220/230/240VAC
Transfer Time
AC Mode to Battery Mode
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Victor 1U 6KL
CAPACITY
600VA/5400W
PHASE
Single phase(L+N+PE)
Voltage Range
110-300VAC±3% at50% load;176-300VAC ±3% at 100% load
Frequency Range
46~54Hz / 56~64 Hz
Power Factor
≧0.99 @ nominal voltage (100% load)
THDi
≦4% @100% load
Voltage Regulation
± 1%
Output Voltage
208*/220/230/240VAC
Waveform (Batt. Mode)
Pure Sine Wave
Current Crest Ratio
3:1(max.)
Frequency Range (Synchronized Range)
46~54Hz / 56~64 Hz
Overload
AC Mode
Battery Mode
93%(max.)
AC Mode
95%(max.)
Charging Current
6.0A(max.)
Charging Voltage
210VDC±1%
Battery Connector
2 Poles(50A max.)
Altitude
0~2000meters without derating;2000~3000 meters,derating 1% every 100 meters;＞3000 meters, not working
Noise Level
Less than 55dBA @ 1 Meter
Humidity
0~95% RH @ 0- 40°C (non-condensing)
Dimension, D X W X H (mm)
550 X 438 X 44
Net Weight (kgs)
9.5
Optional SNMP
Power management from SNMP manager and web browser
USB
Supports Windows 2000/2003/XP/Vista/2008/7/8, Linux and MAC
Optional WiFi module
APP for Wifi linking
LCD
Load level, Battery level,AC mode, Battery modeand fault indicators
Communication ports
USB, Mini Slot,WiFi
Emergency Power Off (EPO)
YES
Model Name
LIO 192003
Nominal DC Voltage
192VDC
Cell Type and nominal capacity
LiFeO4 and 3.2V/3Ah
continuous Discharge Current
30A max.
Com Ports
RS485(Pack to UPS),CAN(pack to pack)
capacity Extension
YES, max up to 3 packs
Backup Time
5400W @ 4 min. / 4800W @ 6 min.
