Scudo
Scudo 400–600VA UPS
Reliable offline UPS for entry-level protection
Voltage
220/230/240 VAC
Frequency
50 Hz
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Scudo 400
CAPACITY
400 VA / 200 W
Voltage Range
180-270 VAC
Output Voltage
220/230/240 VAC
Frequency Range (Batt. Mode)
50 Hz ± 1 Hz
Waveform (Batt. Mode)
Simulated Sine Wave
Voltage Regulation (Batt. Mode)
± 10%
Transfer Time (Typical)
2-6 ms
Battery Type & Number
12 V/4.5 AH x 1
Typical Charging Time
8 hours recover to 90% capacity
AC Mode
Green lighting
Battery Mode
Green flashing every 10 seconds
Fault
Red lighting
Low Battery
Green flashing every second and red lighting
Dimension, D X W X H (mm)
166 x 161 x 89.2
Net Weight (kgs)
2.25
Operating Humidity
0~90% RH
Operating Temperature
0- 40°C (non-condensing)
Scudo 400
400 VA / 200 W
Scudo 600
600 VA / 300 W
