Outdoor 500VA–3kVA Weatherproof UPS
IP65 rated for telecom and outdoor enclosures
Nominal Voltage
120 VAC
Frequency
50Hz/60Hz ± 0.1%
Waveform
Pure Sine Wave
Transfer Time
Generator Mode (max.)
Efficiency
AVR Mode
Battery Type
AGM
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Outdoor 2000A / UPS-2000A
Rated Power
2000 VA / 1600 W
Acceptable Voltage Range
88 ~152 VAC user programmable. Default: 100~130VAC
Frequency Range
60/50 Hz (Auto sensing)
Voltage Regulation (Batt. Mode)
120 VAC ± 5%
THD (Batt. Mode)
<3% @ Full resistive load
Charging Current
2A/4A/6A/8A/10A (Adjustable)
Low DC Warning Voltage
46VDC ± 0.4VDC @ no load
Nominal DC Voltage
48 VDC
Battery Mode
Green LED flashing
Bypass Mode
Green LED on
Fault without Output
Red LED on
No Output
Green LED Off
Warning with Output
Yellow LED on
Operating Temperature
-40°C to 80°C
Humidity
5% to 95% Relative Humidity(Non-condensing)
Noise Level
< 48dB
Dimension, D X W X H (mm)
240 x400 x 133
Net Weight (kgs)
13
Type of Mechanical Protection
IP 20
EMI Compliance
Class A FCC/CISPR [EN50091-2: 1995]
Surge Protection
IEEE/ANSI C.62.41 & 2KV, L-N
Dry Contact Rating
3A @ 125VAC
Outdoor 2000A / UPS-2000A
2000 VA / 1600 W
Outdoor 2000E / UPS-2000E
2000 VA / 1600 W
