OtimaTower
Otima II Tower 800VA–5kVA UPS
Online double conversion for servers and NAS
Nominal Voltage
110/115/120/127 VAC or 208/220/230/240 V
Transfer Time
Typical 2-6 ms, 10ms max.
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Otima II T 800
CAPACITY
800 VA / 720 W
Acceptable Voltage Range
81-152 VAC or 162-290 VAC
Frequency Range
60/50 Hz (auto sensing)
Output Voltage
110/115/120/127 VAC or 208/220/230/240 VAC
Frequency Range (Batt. Mode)
50 Hz or 60 Hz ± 1 Hz
Waveform (Batt. Mode)
Pure Sine Wave
Voltage Regulation (Batt. Mode)
± 1.5% (before battery alarm)
Current Crest Ratio
3:1
Harmonic Distortion
2% max @ 100% linear load, 5% max @ 100% non-linear load (before low battery alarm)
Battery Mode
≧ 88%, up to 90% @ nominal battery voltage
Buck & Boost Mode
95%
ECO Mode
97%
Charging Voltage
27.4 VDC ± 1%
Charging Current (max.)
1.5 A
Typical Recharge Time
4 hours recover to 90% capacity
Battery Type & Numbers
12 V/7 Ah x 2
Full Protection
Overload, discharge, and overcharge protection
LCD Display
AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, and Low Battery
Low Battery
Sounding every 2 seconds
Overload
Sounding every second
Fault
Continuously sounding
Operating Humidity
0~90% RH @ 0- 40°C (non-condensing)
Noise Level
Less than 45dB
Net Weight (kgs)
11.7
Dimension, DXWXH (mm)
397 x 145 x 220
Optional SNMP
Power management from SNMP manager and web browser
Smart RS-232 / USB
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8/10, Linux, and MAC
Model
Otima II T 5K
Otima II T 800
800 VA / 720 W
Otima II T 1.1K
1100 VA / 990 W
Otima II T 1.5K
1500 VA / 1350 W
Otima II T 2K
2000 VA / 1800 W
Otima II T 2.5K
2500 VA / 2250 W
Otima II T 3K
3000 VA / 2700 W
Otima II T 5K
5000 VA / 4500 W
