NanoAPFC
Nano APFC 400–800VA UPS
APFC sine-wave output for sensitive electronics
Voltage
110/120 VAC or 220/230/240 VAC
Frequency
60/50 Hz (auto sensing)
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Nano-APFC 400
CAPACITY
400 VA / 240 W
Voltage Range
90-145 VAC / 180-270 VAC
Output Voltage
110/120 VAC or 220/230/240 VAC
Frequency Range (Batt. Mode)
50 Hz or 60 Hz ± 1 Hz
Waveform (Batt. Mode)
Simulated Sine Wave
Voltage Regulation (Batt. Mode)
± 10%
Transfer Time (Typical)
2-6ms
Battery Type & Number
12 V/4.5 AH x 1
Typical Charging Time
8 hours recover to 90% capacity
AC Mode
Green lighting
Battery Mode
Green flashing every 10 seconds
Fault
Red lighting
Low Battery (Batt. Mode)
Green flashing every second and red lighting
Low Battery
Sounding every second
Dimension, D X W X H (mm)
228 x 82.5 x 207 (vertically stand)
Net Weight (kgs)
2.2
USB Port (option)
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8/10, Linux, and MAC
Operating Humidity
0~90% RH
Operating Temperature
0- 40°C (non-condensing)
Nano-APFC 400
400 VA / 240 W
Nano-APFC 600
600 VA / 360 W
Nano-APFC 800
800 VA / 480 W
