Galleon One 1–3kVA LiFePO4 RT/Tower UPS
Lithium battery online UPS, rack or tower
Nominal Voltage
100/110/115/120 /127 VAC or 200/208/220/
Transfer Time
AC to Battery Mode
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Galleon One LiFePO4 1K
CAPACITY
1000 VA / 900 W
PHASE
Single phase with ground
Acceptable Voltage Range
55-150 VAC ± 3% or 110-300 VAC ± 3% @ 50% load; 80-150 VAC ± 3% or 160-300 VAC ± 3% @ 100% load
Frequency Range
40~70 Hz
Power Factor
≧0.99 @ nominal voltage (100% load)
THDi
≦5% @nominal input voltage
Output Voltage
100*/110/115/120 /127 VAC or 200*/208*/220/230/240 VAC
Frequency Range (Batt. Mode)
60 Hz ± 0.1Hz or 50 Hz ± 0.1Hz
Waveform (Batt. Mode)
Pure Sine Wave
Voltage Regulation (Batt. Mode)
± 1%
Current Crest Ratio
3:1
Harmonic Distortion
2% max @ 100% linear load, 5% max @ 100% non-linear load (before low battery alarm)
Frequency Range (Synchronized Range)
57~63 Hz or 47~53 Hz
Battery Mode
87%
ECO Mode
≧96% @ full charged battery
AC Mode
89% @ full charged battery
Battery Voltage
25.6 V
Charging Current
1/2/4/6/8A (max.), adjustable through LCD
Charging Voltage
28 VDC ± 1%
Battery Type**
LiFe 247500
Battery Lifecycle
> 2000
Single Cell Type
LFP26650P-260
Battery Number**
1
Battery Cell Configuration
8S3P
Battery VAH(Factory Setting)
7.5Ah
Autonomy Time @ Full load
9.5 minutes
Charging Mode
2 stage charging management(CC-CV)
Typical Recharge Time
1.5 hours recover to 90% capacity
Operating Humidity
20-95 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 45dB
RT Model
Dimension, DXWXH (mm)
Tower Model
Dimension, DXWXH (mm)
Optional SNMP
Power management from SNMP manager and web browser
Smart RS-232 / USB
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, and MAC
EMC/Safety
CE (EMC: EN62040-2 C2) for HV models, FCC (Class A) for LV models, Battery Pack comply to UL1973
Galleon One LiFePO4 1K
1000 VA / 900 W
Galleon One LiFePO4 1.5K
1500 VA / 1350 W
Galleon One LiFePO4 2K
2000 VA / 1800 W
Galleon One LiFePO4 3K
3000 VA / 2700 W
