Galleon III RT 6/10kVA Rack Online UPS
Rack-mount online UPS with parallel capability
Nominal Voltage
208/220/230/240 VAC
Transfer Time
AC Mode to Batt. Mode
Battery Type
Lead acid battery
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Galleon III RT 6K(L)
CAPACITY
6000 VA / 6000 W
PHASE
1 phase in / 1 phase out
Voltage Range
110~300VAC ± 3 % at 60% load 176~300VAC ± 3 % at 100% load
Frequency Range
46~54 Hz or 56~64 ; Hz40 ~ 70 Hz (In generator mode)
Power Factor
≧ 0.99 @ full load
THDi
<4% @100% Load
Output Voltage
208*/220/230/240 VAC
AC Voltage Regulation (Batt. Mode)
± 1%
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Waveform (Batt. Mode)
Pure Sinewave
Current Crest Ratio
3:1 (max.)
Harmonic Distortion
≦1 % THD (Linear Load), ≦ 4 % THD (Non-linear Load)
Frequency Range (Synchronized Range)
46~54 Hz or 56~64 Hz
Overload
AC Mode
Battery Mode
0.92
AC Mode
0.95
Charging Voltage
(13.65VDC x battery number) ± 1%
Numbers
16-20**
Charging Current (max.)
2A (Default) ,1A/2A/4A/6A/8A adjustable
Noise Level
Less than 55dBA @ 1 Meter
Operation Humidity
20-90 % RH @ 0- 40°C (non-condensing)
Net Weight (kgs)
11
Dimensions, D x W x H(mm)
509 x 438 x 88 (2U)
Optional SNMP
Power management from SNMP manager and web browser
Smart RS-232 / USB
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux and MAC
Galleon III RT 6K(L)
6000 VA / 6000 W
Galleon III RT 10K (L)
10000 VA / 10000 W
