CFL
CFL DC UPS
DC backup for CFL lighting and gate systems
Voltage
230 VAC
Waveform
DC Output
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
CFL UPS
CAPACITY
50 VA/40 W
Voltage Range
100 VAC-300 VAC
Output Voltage (AC Mode)
100 VDC-300 VDC
Output Voltage (Batt. Mode)
160-230 VDC ± 10%
Battery Type & Number
12V 7Ah x 1
Typical Charging Time
6 hours recover to 90% capacity
Floating Charge Voltage
13.7 VDC ± 1.5%
Charging Current
1 A
Bulk charging voltage
14.5 VDC ± 1.5%
Battery Voltage
12 VDC
Low Battery (Batt. Mode)
Yellow flashing every second
Normal battery voltage at Battery Mode
Yellow lighting
Output short-circuited
Red lighting
Overcharge
Red LED staying on for one second and off for 4 seconds
Overload
Red flashing rapidly every 0.5 second
Charging battery at Line Mode
Green flashing every 2 seconds
Full battery at Line Mode
Green lighting
Dimension, D X W X H (mm)
209 x 87 x 200
Net Weight (kgs)
2.7
Operating Humidity
0~90% RH @ 0- 40°C (non-condensing)
Noise Level
Less than 40dB
CFL UPS
50 VA/40 W
