Ara 1–1.5kVA Line-Interactive UPS
Compact UPS for retail and POS systems
Voltage
110/120 VAC or 220/230/240 VAC
Transfer Time
6ms typical, 10ms max
Every unit factory-tested: full-load aging + 40-point QC before shipping.
Full Specifications
MODEL
Ara 1000
CAPACITY
1000 VA / 600 W
Voltage Range
81～132VAC/86-142VAC or 170~280VAC
AC Voltage Regulation (Batt. Mode)
± 10%
Frequency Range (Batt. Mode)
50 Hz/ 60 Hz ± 1 Hz
Waveform (Batt. Mode)
Pure Sine Wave
Battery Type & Number
12 V/9 Ah x 1
Typical Charging Time
6-8 hours recover to 90% capacity
Operating Humidity
0~90% RH @ 0- 40°C (non-condensing)
Noise Level
Less than 40dB
Dimension, D X W X H (mm)
308 x 99 x 280
Net Weight (kgs)
9.2
Ara 1000
1000 VA / 600 W
Ara 1500
1500 VA / 900 W
