3A3PT25–200 kVA
ARRAY 3A3 PT Modular UPS (25–200 kVA)
Hot-swappable modular UPS with >96% double-conversion and >99% energy-saver efficiency — scale power in minutes, service without downtime.
Power Rating
25–200 kVA
Topology
Modular, double conversion
Efficiency
> 96% (online) / > 99% (ESS)
Input
220/380, 230/400, 240/415 VAC
Output
220/380, 230/400, 240/415 VAC
Parallel
up to 4 units
Backup
external battery, configurable
Full Specifications
Overview
Series
ARRAY 3A3 PT
Power Rating
25–200 kVA, 0.9 PF
Topology
Modular online double conversion, three-level bridge IGBT PWM control
Frame Options
75 kVA frame (600×1100×2020 mm) and 200 kVA frame (608×1010×2050 mm)
Degree of Protection
IP20
Standards
IEC 62040-1 / -2 / -3, RoHS
Input
Rated Input Voltage
220/380, 230/400, 240/415 VAC
Input Wiring
3ph + N + PE
Frequency Range
40–72 Hz (50/60 Hz rated)
Input Power Factor
0.99 @ 100% load
Input THD
< 3%
Soft Start
Yes
Output
Rated Output Voltage
220/380, 230/400, 240/415 VAC, 50/60 Hz
Output Wiring
3ph + N + PE
Output THD
< 1.5% (100% linear load); < 3% (100% non-linear load)
Permitted Load Power Factor
0.8 lagging to 0.8 leading
Overload (Inverter)
125% for 10 min; 150% for 60 s; > 150% for 300 ms
Overload (Bypass)
Continuous < 115%; 1000% for 10 ms
Efficiency (Double Conversion)
> 96%
Efficiency (Energy Saver)
> 99%
External Paralleling
Up to 4 units, hot-parallel technology
Battery
Battery Type
VRLA, AGM or GEL
Battery Quantity
36–42 blocks (default 40)
Charging Method
Intelligent battery management or continuous float
Temperature Compensation
Optional
Battery Start
Yes (cold start)
Communications
Communication Bays
3 mini-slots
Serial Ports
Built-in host and device USB
Connectivity
5 building alarm inputs + dedicated EPO
Software
Santak Winpower
Display Languages
English, French, Portuguese, Spanish, Russian
Environment
Operating Temperature
0–40 °C
Noise @ 1 m, 25 °C
< 65 dBA (double conversion)
Altitude
1000 m max @ 40 °C
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
